Basic hardware | Image sensor | 1/4" Color CMOS Sensor(OV9715) |
Processor | GM8126 | |
Max. resolution | 1280 * 720Pixels (720P) | |
Lens | Lens type | Glass Lens |
Viewing angle | 60 degree | |
Lens spec | f=4~9mm, 3X optical zoom | |
Day/Night | IR-CUT | |
Domain name | Server | P2P server |
Video | Compression Format | H.264 |
Image Frame Rate | 30fps (720P); 30fps (VGA), 30fps (QVGA) | |
Image Resolution | 1280 * 720(720P); 640 * 480(VGA), 320 * 240(QVGA) | |
Flip Mirror Images | Vertical / Horizontal | |
Mode | 50Hz / 60Hz | |
Video Parameters | Brightness, Contrast | |
Audio | Sound | No |
Communication | Ethernet | RJ-45 Interface 10/100Mbps |
Supported Protocol | HTTP/DHCP/IP/TCP/UDP/FTP/SMTP/DDNS/UPnP/ONVIF/RTSP | |
Wireless | IEEE 802.11b/g/n | |
Code Rate | 720P 30 frames 4Mbps; VGA 15frames 512Kbps; QVGA 8frames 200Kbps | |
Wireless Security | 64/128bit WEP Encryption | |
Physical Parameter | Pan/Tilt Angle | Horizontal: 355 degree, Vertical: 90 degree |
Infrared Light | 22 IR LEDs, night vision up to 20 meters | |
Operating Environment | Operating Temperature | 0 ~ 55 Celsius degree / 14 ~ 122 Fahrenheit degree |
Operating Humidity | 20% ~ 85% RH (Non-condensing) | |
Storage Temperature | -10 ~ 60 Celsius degree / 14 ~ 140 Fahrenheit degree | |
Storage Humidity | 0% ~ 90% RH (Non-condensing) | |
PC Configuration | CPU | 2.0Ghz or above (Suggested 3.0Ghz) |
Memory Size | 512MB or above (Suggested 1.0GHz) | |
Graphics Card | 64M or above | |
Supported OS | Microsoft Windows XP/Vista/Windows7 | |
Supported Browsers | Internet Explorer 6.0 and above or compatiable browser | |
Mobile phone browser | iPhone/iPad | Search "Viewworld" from App Store and install it |
Android | Install "CamView.apk" from CD | |
Others | Power adapter | Input: 100-240V, 50/60Hz, 0.5A; Output: 5V 2000mA |
Size | Item size: Approx. 24 * 12 * 22cm / 9.45 * 4.72 * 8.66in | |
Package size: Approx. 26.5 * 26 * 18cm / 10.43 * 10.24 * 7.09 | ||
Weight | Item weight: Approx. 1210g / 2.67Lb | |
Package weight: Approx. 1739g / 3.84Lb | ||
Certification | Certificate | CE FCC RoHS |
Questions & Answers
A The distance is more than 30m.
