This professional digital insulation tester has stable performance and reliable result. It adopts the DC Voltage convetor of low consumption and high converter ratio inductance energy storage. With large LCD display, easy to read.
Features:
Large LCD 1999 counts (3 1/2digits) display with backlight, easy to read.
Reliable insulation resistance & AC voltage tester with stable performance.
Locking function of test button, wide measurement range, convenient to use.
Come with useful accessories such as 3pcs of auxiliary test wire, 2pcs simple test wire & 2pcs ground support rod.
Perfect overload protection, widely used for insulation resistance check, such as electric, cable, electrical and mechanical equipment, telecommunication equipment and electrical facilities.
Powered by 8 batteries(not included), with low battery indication and 200V AC voltage test.
Specifications:
Brand Name: RuoShui
Color: Black + Orange
Material: ABS Plastic
Display: LCD Display with Backlight, 1999 (3 1/2digits)
Range Control: Manual Range
LCD Size: 80 * 51mm
Over Range Indication: Display "1"
Resistance Range: 20Ω/200Ω/2000Ω
Resistance Resolution: 0.01Ω/0.1Ω/1Ω
AC Voltage Range: 200V
AC Voltage Resolution: 0.1V
Application: Power system, electrical equipment, lightning protection equipment
Terminal Position: P(Potential Pole), C(Current Pole), E(Ground Pole), ACV G(200V)
Input Impendance: 1MΩ
Function: Alarm Function Red indicator light is illuminated
Low Battery Indication: YES
LCD Backlight: YES
Alarm Light Display: YES
Alarm Buzzer: YES
High Voltage Indication: YES
Over Load Indication: YES
Automatic Discharge: YES
Test Voltage Vice Display: YES
10MΩ Internal Resistance Test: YES
Power Supply: 8 * 1.5V AA Alkaline Battery (Not Included)
Working Temperature/Humidity: 0～40℃, 30～85%RH
Storage Temperature/Humidity: 0～50℃, 30～85%RH
Item Size: Approx. 180 * 120 * 65mm / 7.1 * 4.7 * 2.6in
Item Weight: 505g / 17.8oz
Package Size: 28 * 25 * 12cm / 11.0 * 9.8 * 4.7in
Package Weight: 2554g / 90.1oz
Package List:
1 * Earth Resistance Tester
2 * Ground Support Rod
3 * Auxiliary Test Wire (5m Green Wire, 10m Yellow Wire, 15m Red Wire)
2 * Simple Test Wire (1.6m Green Wire, 1.6m Red Wire)
1 * Shoulder Strap
1 * Canvas Bag
1 * Use Manual (English)
